| Type |
MPPT |
| Battery voltage [V] |
12, 24, 48 |
| Maximum Current 12V Battery [A] |
100 |
| Maximum Current 24V Battery [A] |
100 |
| Maximum Current 48V Battery [A] |
100 |
| Max. PV Array @ 12V [W] |
1450 |
| Max. PV Array @ 24V [W] |
2900 |
| Max. PV Array @ 48V [W] |
5800 |
| Max PV Open Circuit Voltage 12V [V] |
150 |
| Max PV Open Circuit Voltage 24V [V] |
150 |
| Max PV Open Circuit Voltage 48V [V] |
150 |
| Number of MPPT |
1 |
| Number of Strings/MPPT |
1 |
| Efficiency [%] |
98 |
| Battery Types Supported |
Lead acid, AGM, GEL, Lithium |
| Terminal Block Size [AWG] |
2 |
| Terminal Block Temp Rating [C] |
90 |
| Ambient temperature [C] |
-30 to +60 |
| Grounding |
Negative |
| Dimensions [cm] |
8.5 x 11.6 x 4.1 |
| Weight [kg] |
4.5 |
